Single Potentiostat

 VersaSTAT Series

<VersaSTAT3>
• Voltage: ±12 V
• Current range: ±200 nA(6 pA Resolution) down to± 4 pA(122aA)
• EIS: 1 MHz (옵션)


<VersaSTAT4>
• Voltage: ±12 V
• Current range: ±4 nA(122 fA Resolution) down to± 4pA(122aA)
• EIS: 1 MHz (옵션)

<VesaSTAT3F>
• Voltage: ±12 V
• Current range: ±4 nA(122 fA Resolution) down to± 4pA(122aA)
• EIS: 1 MHz (옵션)

PARSTAT Series

<PARSTAT 4000A>
• Voltage: ±48 V
• Max. Current output: ±4 A up to ±20 A
• Min Current Range: ±40 pA (1.2 fA resolution down to  ±80 fA(2 aA)
• EIS: 10 MHz

<PSRATAT 3000A>
• Voltage: ±48 V
• Max. Current output: ±4 A up to ±20 A
• Min Current Range: ±4 nA (122 fA resolution down to ±4 pA(122 aA)
• EIS: 7 MHz

<PARSTAT 3000A-DX>
• Voltage: ±30 V (ch. 2)
• Max. Current output: ±2 A(ch.1)
• Min Current Range: ±4 nA (122 fA resolution down to ±4 pA(122 aA) (ch.1)
• EIS: 7 MHz (ch. 2)
          1 MHz (ch. 1)

 Apps XM Series

<EchemLab Xm>
• Voltage: ±100 V
• Max. Current output: ±300 mA up to ±100 A
• Min Current Range: ±30 nA (1.5 pA reaolution)
• EIS: 10 μHz to 1 MHz

<EnergyLab XM>
• Voltage: ±8 V (HV : ±100 V)
• Max. Current output: ±2 A up to ±100 A
• Min Current Range: ±30 nA(1.5 pA reaolution)
• EIS: 10 μHz to 1 MHz

ModuLab XM ECS

<ModuLab XM ECS>
• Voltage: ±8 V up to ±100 V)
• Max. Current output: ±300 mA up to ±100 A
• Min Current Range: ±30 nA(1.5 pA reaolution) to ±30 pA(1.5 fA)
• FRA Option: 10μHz ~ 300KHz 또는 1MHz 선택 가능 / 10uΩ ~ 100TΩ측정 가능

12XX Series

<1287A>
• Voltage: ±14.5 V, ±20 V
• Max. Current output: ±2A up to ±100 A
• EIS: 1 MHz with 1260A
           1 MHz with 1255B
           20 kHz with 1253A
           65 kHz with 1250E

<1280Z>
• Voltage: ±14.5 V, ±20 V
• Max. Current output: ±2A up to ±100 A
• EIS: 20 kHz

Multi Potentiostat

PARSTAT MC

<PARSTAT MC>
• Voltage: ±10 V(PMC-200), ±12 V(PMC-1000), ±30 V(PMC-2000A)
• Max. Current output: ±2 A(PMC-1000), ±1 A(PMC-2000A/ PMC-200)
• Min Current Range:  ±2 uA(PMC-200), ±4 nA to ±4 pA (PMC-1000), ±4 nA(PMC-2000A)
• EIS: 10µHz ~ 7MHz
• 최대 20 채널

1470E

<1470E>
• Voltage: ±10 V
• Max. Current output: ±2 A(PMC-1000), ±1 A(PMC-2000A/ PMC-200)
• Min Current Range: ±4 A
• EIS: 10µHz ~ 1MHz
• 최대 96채널

■ Solar Test Systems

□  ModuLab XM PhotoEchem

<ModuLab XM PhotoEchem>
• Wavelength Range: 350 nm - 1100nm
• Intensity Range: 6 Decades (with ND Filter)
• Max Beam Diameter/cell size : 1cm
• Potentiostat
   - Voltage Range : ±8 V (옵션 모듈 추가 시 ±100 V)
   - Maximum Current : ±300mA(옵션 모듈 추가 시 ±2)
   - Current Range : 300mA to 30nA
   -Frequency Range : 10uHz to 1MHz or 10uHz to 300kHz

□ SolarLab XM

<SolarLab XM>
• Wavelength Range: 350 nm - 1100nm
• Intensity Range: 6 Decades (with ND Filter)
• Max Beam Diameter/cell size : 1cm
• Voltage Range : ±8V, resolution : 1µHz
• Current Range : ±300 mA, resolution : 1pA
